Mondraker ARID S - Denim Blue

Frame

Sizes

S: 410mm / M: 450mm / ML: 480mm / L: 510mm / XL: 540mm

Fork

Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork

Headset

Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing.

Stem

Onoff S3 6061 T6 Alloy, 31.8mm barbore, rise: -7º, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm

Handlebar

OnOff S3 GR 16º bar flare. Width sizes S size: 440mm M size: 440mm ML size: 460mm L size: 460mm XL size: 460mm

Grips

OnOff HEX Bartape

Seatpost

Onoff S3 0-R, diameter 27.2mm, length 400mm

Saddle

FIZIK Terra Argo X5 140mm

Front brake

Rear brake

Shimano GRX RX-610, RX-400 caliper, CL-800 ice tech 160mm centerlock rotor, resin pad

Brake lever

Shimano GRX RX-610, contact point adjustment, tooled reach adjust, aluminium lever.

Rims

Mavic Allroad Disc, UST, 25mm internal width, hookless, infinity hubs, 24 spokes front, 28 spokers rear

Spokes

Mavic Steel double butted flat spokes

Front hub

Mavic, 12x100mm, IS 6 bolts

Rear hub

Mavic infinity hub, 12x142mm, XD ID360 Ratchet system, IS 6 bolts, MS Freehub

Front tire

Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead

Rear tire

Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead

Crankset

Shimano GRX RX-610, S size: 170mm M size: 170mm ML size: 172,5mm L size: 172,5mm XL size: 175mm, CL 49,7

Rings

Shimano 40T, direct mount, steel

Bottom bracket

Token T47 BSA sealed bearings, 85,5mm

Chain

Shimano SLX M7100, Quick link

Rear derrailleur

Shimano GRX RX-822-GS, 12s

Shift levers

Shimano GRX RX-610 dual control, alloy lever

Casette

Shimano SLX M7100, hiperglide+,10-45, 12s

Weight

10,9 kg
